XV100 is the ideal partner for easyE4. Items can be conveniently displayed through the XV-102-A0-35TQRB-1E4 touch screen. The standard running GALILEO 3.5-inch display provides an economical and efficient solution for remote and powerful visualization.
The XV100 touch display PLC can be programmed using CODESYS V2 or CODESYS V3. Visualization can be achieved using Eaton’s Galileo software. In addition, CODESYS can also be used for visualization purposes. The free SWD Assist software supports the configuration of SmartWire DT cables. Thanks to the integrated parts list function, order processing has become fast and simple.
Eaton’s Moller XV100 series touch display series provides compact, robust, and flexible solutions for all space limited automation applications. These devices can be used as HMI control panels or alternatively as HMI/PLC combinations with integrated PLC functionality. The XV100 device is equipped with a TFT display screen using resistive touch technology, ranging in size from 3.5 inches to 10.4 inches. In addition to the built-in Ethernet interface, according to the device type, CAN, PROFIBUS, RS232, and RS485 interfaces are also provided, as well as connections to SmartWire DT.
The visualization device XV-363 is particularly suitable for applications that require infrared touch on sturdy surfaces and smooth operation. These devices are available in 5.7-inch, 10 inch, and 12 inch diagonal options. These devices can be used as both HMI operation panels and HMI-PLC combination devices with integrated PLC functionality. For these two applications, the device provides multiple communication connections through Ethernet, CANopen, Profibus, or serial protocols. Use the powerful Galileo project planning tool for project planning, which provides multiple possibilities for intuitive application creation. For example, this includes the integration of multimedia elements. Eaton provides XSOFT-CODESYS software for programming PLC functions.
Manufacturer Series XV-102
Display type TFT
Display screen size 3.5 inches
Display resolution 320 x 240 pixels
Display Color Color
Number of ports 2
Port type Ethernet, RS485
Processor speed 400MHz
Onboard memory 125 (NVRAM) KB, 64 (DRAM) MB, 64 (NAND) MB
Backlight, yes
Power supply voltage 24V DC
Intellectual property level IP20 IP65
Depth 30mm
Width 100mm
Working temperature+50 ° C
Working temperature 0 ° C
Length 136mm
Aspect 136 x 100 x 30mm
