Allen-Bradley 1762-IR4 – High Precision Temperature Sensing Module

    The Allen-Bradley 1762-IR4 Resistance Module is designed for high precision temperature sensing applications in industrial environments. It provides reliable data acquisition and control, making it ideal for various manufacturing processes where accurate temperature measurement is critical.

Manufacturer:Allen-Bradley

Model Number:1762-IR4

Module Type:Resistance Module

Input Range:0-100 ohms

Accuracy:+/- 0.1% of reading

Operating Voltage:12-24 VDC

Environmental Rating:NEMA 4X / IP65

Operating Temperature Range:-40°C to +85°C

Response Time:<1 second

    This resistance module from Allen-Bradley is engineered with precision in mind, ensuring that every temperature reading is accurate and reliable. Its design is robust, capable of enduring the rigorous conditions often found in industrial settings.

    With a wide input range from 100 Ohms to 20 kOhms, this module can handle diverse temperature measurement requirements. Its accuracy stands at +/-0.25% of reading plus one count, providing highly dependable data.

    Suitable for applications requiring precise temperature monitoring, such as process control systems, HVAC, and more, the Allen-Bradley 1762-IR4 offers quick response times under 1 second, enabling real-time adjustments and optimizations.

    The module operates efficiently on a power supply ranging from 10 to 30 VDC, with a current consumption less than 15 mA, making it energy-efficient without compromising performance.

    Installation and integration are straightforward thanks to its compact design and compatibility with existing industrial control systems.
