BENTLY 146031-01 3500/22M meets the requirement of operating temperature range from 1 to 100
146031-01 3500/22M is a compatible PCI mezzanine card (PMC) module that provides dual or quad channel 10Base-T/100Base TX/1000Base-T interfaces. Transparent 64 bit, up to 133 MHz PCI-x/PCI to PC ridge, and a PCIe switch provide access to Intel 210IT Gigabit Ethernet controllers. Each Ethernet interface supports transfer rates of 10, 100, and 1000 mbit, and is equipped with 16 mbit serial flash memory to support PCIe and SCSI booting.
The two/four Ethernet interfaces of 146031-01 3500/22M are capable of executing an automatic negotiation algorithm, which allows the following two link partners to determine the optimal link parameters. TPMC895 supports IEEE 1588/802.1 Suppression Time Protocol (PTP) and IEEE 802.1 qavadio/video bridging (AVB) traffic ping (with software extensions).
TPMC895-10R provides 4 10/100/1000 Mbps/Ethernet connections through RJ45 interface on the front panel. TPMC895-11R routes 4 Ethernet ports to BackI/O P14 interface, without RJ45 interface in front.
The TPMC895-2R provides two 10/100/1000 Mbps/set subnet connections through the RJ45 interface front panel. TPMC895-21R routes two Ethernet ports to BackI/O P14 interface, without RJ45 interface in front.
TPMC895-30R is a TPMC895-10R with an additional I/O terminal P14 for IEEE 1588 auxiliary device connections.
All ports are electrically isolated from the Ethernet controller and LEDs on the board indicating different work activities. This module meets the requirement of operating temperature range from □ to □
146031-01 3500/22M functions include
Exterior specifications: 64 bit PMC module compliant with IEEE P1386/P1386.1 standard
Motherboard size: 149mm x 74mm
PCI 3.0 (up to 66 MHz) and PCI-X 2.0a (up to 133 MHz) interconnect interfaces
3.3V PCI signal and 5V I/O fault tolerance
Two/four Intel I210IT Gigabit Ethernet controllers
2/4 RJ45 connector or reverse I/O P14 connector
1000Base-T
100Base-TX
10 Base-T
IEEE 1588/802.1 as precision time protocol(PTP)
-V1 and V2 PTP frame formats
-TPMC895-30R, with auxiliary equipment supporting P14 connector through backend I/O
IEEE 802.1Qav Audio/Video Bridge (AVB) Traffic Shaper (with software extensions)
16 mbit serial flash memory, used for rolling back configuration data for each channel and providing memory for boot ROM
Operating temperature ≤ to, requiring a constant airflow of 2m/s
MTBF (MIL-HDBK217F/FN2 GB)
-TPMC895-10R: 427000 hours
-TPMC895-11R: 58700 hours
-TPMC895-2R: 59300 hours
-TPMC895-21R: 679000 hours
-TPMC895-30R: 389000 hours
