Brand: AMAT

Model: 0100-71313

Weight: Free shipping
The power port is an accessory that can be installed behind the power rack. It can convert the alarm signals generated by the power box and power rack into voltage free alarm contacts for system use. System usage. It consists of a printed circuit board (PCB) with connectors, relays, and other electronic components. Alarm contacts are provided through a connector for easy wiring in the system. The system provides a power source for the power port, which is wired to the same connector. The pin layout of the connector is displayed in the pins of the connector. There is a 25 way D-type female connector installed on the power rack, and the power port is connected to it. connect. The power port is fixed to the power rack with D-shaped socket screws. The power port is equipped with a 25 way D-type female connector, which allows the connection of the power rack to be extended to the power controller. The connection can be extended to the power controller or to other racks to achieve current sharing and use power rack interconnect cables. The power controller is powered by a 24V power supply from the power port through pin 7. When CON2 on the power port is connected to the power rack, the power controller will be powered through pin 7. Connect CON 2 of the power port to the power controller.
